KonFUSED 0 Gauge Negative Battery Terminal

$19.99

Product code: FBT-40N
In Stock Ships Monday, 11/18/2024
Estimated Delivery . Wednesday, November 20th - Friday, November 22nd on standard shipping

380 in stock

Choose attributes above to add to cart.

Shipping

Fast 2-3 Day Standard Delivery

Warranty

One Year warranty on all KnuKonceptz products

Returns

No restocking fees on timely returns

Payment

payment payment payment payment payment

Item description

The KnuKonceptz FBT-40N is the negative match to our FBT-40 Fused Battery Terminal. Specifically machined for the negative battery post, the FBT-40N has 4 non-insulated compression ports. From the factory three of these ports accept 0 gauge and one port accepts 4 gauge. Additional compression fittings may be purchased to offer any combination of 0, 2 or 4 gauge output, The FBT-40N allows access to your OEM battery terminal via our top post adpater – TPA-NEGl. Some simple modification to the FBT-40N smoked poly carbonate cover is required to allow access to this port.

The FBT-40 battery terminal clamps to your battery post with two insulated allen screws. These screws must be tightend evenly during installation to avoid binding or damage to the terminal.

Prior to installing, be sure you have room for the FBT-40. Minimum clearance required is 20mm.  Certain battery types lack the clearance required to mount the FBT terminals.

Item description

Item description

The KnuKonceptz FBT-40N is the negative match to our FBT-40 Fused Battery Terminal. Specifically machined for the negative battery post, the FBT-40N has 4 non-insulated compression ports. From the factory three of these ports accept 0 gauge and one port accepts 4 gauge. Additional compression fittings may be purchased to offer any combination of 0, 2 or 4 gauge output, The FBT-40N allows access to your OEM battery terminal via our top post adpater - TPA-NEGl. Some simple modification to the FBT-40N smoked poly carbonate cover is required to allow access to this port.
The FBT-40 battery terminal clamps to your battery post with two insulated allen screws. These screws must be tightend evenly during installation to avoid binding or damage to the terminal.
Prior to installing, be sure you have room for the FBT-40. Minimum clearance required is 20mm.  Certain battery types lack the clearance required to mount the FBT terminals.

Specifications

UBT Battery
FinishNickel Chrome
Outputs0 Gauge, 4 Gauge, 8 Gauge + OEM Connection
Dimensions2.625″(W) x 2.0″(H) x 1.125″(D) with cover
Warranty1 Year
Insulated Cover IncludedYes

Specifications

KonFUSED 0 Gauge Negative Battery Terminal
Dimensions with Cover (L x W x H) 3.7" x 2.38" x 1.3"
Outputs Four
Fittings Included Three 1/0 Gauge, One 4 Gauge
Insulated Cover Included Yes
Finish Nickel Chrome

Description

The KnuKonceptz FBT-40N is the negative match to our FBT-40 Fused Battery Terminal. Specifically machined for the negative battery post, the FBT-40N has 4 non-insulated compression ports. From the factory three of these ports accept 0 gauge and one port accepts 4 gauge. Additional compression fittings may be purchased to offer any combination of 0, 2 or 4 gauge output, The FBT-40N allows access to your OEM battery terminal via our top post adpater – TPA-NEGl. Some simple modification to the FBT-40N smoked poly carbonate cover is required to allow access to this port.

The FBT-40 battery terminal clamps to your battery post with two insulated allen screws. These screws must be tightend evenly during installation to avoid binding or damage to the terminal.

Prior to installing, be sure you have room for the FBT-40. Minimum clearance required is 20mm.  Certain battery types lack the clearance required to mount the FBT terminals.

Additional information

Weight 1.5 lbs
Gauge

,

Application

Car, Marine
Usage

Power
Polarity

Frequent questions

  • How is wire secured to this battery terminal?

    The FBT-40 uses compression fittings to secure the cable. Compression connections provide a clean and incredibly strong connection To connect, trip the jacket off the cable; Insert the wire into the fitting; fold the copper strands as shown in the photo; Tighten the fitting into the block, compressing the cable into place. This results in 360 degrees of contact area, unlike set screw blocks that have just the one high pressure point. The Kompression Fitting allows more strand/block interaction, which results in less resistance and more current flow. KonFUSED System Introduction.

  • Is there a difference between the Positive and Negative top post terminals?

    Yes, the Negative top post terminal’s opening is smaller in diameter so that it can not be mounted on the positive battery post and cause a reverse in polarity within the vehicle.

  • Can I purchase additional compression fittings for this model?

    Yes, additional fittings are available for purchase. They are $0.99 each
